1997 Komo VMC40-180
No longer available
1997 Komo VMC40-180
$14,500 (USD)
Location:Kansas
Description
30 Station Side Mounted Tool Changer - Needs adjustment Linear Guides RS 232 Port Interface Extended Memory Coolant System All Available Manuals 208/240 V Z-Axis ballscrew is noisy and will likely need replacing X-Axis thrust bearings and possible rails need replacing
Specifications
| Manufacturer | Komo |
| Model | VMC40-180 |
| Year | 1997 |
| Condition | Used |
| Stock Number | 111209 |
| Control | Fanuc 15M |
| Table Size | 180" x 24" |
| Maximum Table Load | Unlimited - Stationary |
| X-Axis Travel | 180" |
| Y-Axis Travel | 24" |
| Z-Axis Travel | 22" |
| Spindle Taper | CAT 40 V-Flange |
| Spindle Speeds | 100 - 10,000 RPM |
| Spindle Motor | 20 HP |
| Number of Tool Positions | 30 Position Tool Changer |
| Rapid Traverse Rates | 600 IPM |
| Machine Dimensions | 320" x 122" x 102" |
| Machine Weight | 23,500 lbs. |
