1995 Doosan/Daewoo Puma 12LB
Sold
1995 Doosan/Daewoo Puma 12LB
Location:Ohio
Description
15" Hydraulic Chuck Chip Conveyor 2 Speed Geared Head Programmable Tailstock Flood Coolant All Available Manuals
Specifications
| Manufacturer | Doosan/Daewoo |
| Model | Puma 12LB |
| Year | 1995 |
| Condition | Used |
| Stock Number | 117232 |
| Control | Fanuc OT |
| Chuck Size | 15" Hydraulic Chuck |
| Maximum Swing | 22.4" |
| Maximum Swing Over Cross Slide | 14.6" |
| Maximum Cutting Diameter | 19" |
| Maximum Cutting Length | 40.2" |
| Maximum Bar Capacity | 3.0" |
| X-Axis Travel | 10.2" |
| Z-Axis Travel | 41.3" |
| Number of Turret Positions | 10 Station Turret |
| Rapid Traverse Rates X/Z | 480 IPM / 630 IPM |
| Spindle Nose / Spindle Bore | A2-8" / 3.5" |
| Spindle Speeds | 25 - 2,500 RPM |
| Spindle Motor | 35 HP |
| Spindle Torque | 1005 ft./lbs. |
| Tailstock Quill Diameter / Center | 4.3" / MT #5 |
| Machine Dimensions | 141" x 87" x 89" |
| Machine Weight | 16,380 lbs. |
