2004 Mazak Integrex 200-IIIS
Sold
2004 Mazak Integrex 200-IIIS
$79,500 (USD)
Location:Illinois
Description
B Axis Pendulum Head - 225 Degree
Y Axis Capability
Subspindle
Full C Axis on Both Spindles - .0001 Indexing
Live Milling on Upper Turret
8" 3 Jaw Hydraulic Chuck on Main Spindle
8" 3 Jaw Hydraulic Chuck on Subspindle
Chip Conveyor
40 Position Tool Changer
Milling Spindle Synchronous Tapping
3.5" Floppy Disk Drive
PCMCIA Interface - 2 Slots
IC Memory Card Interface
RS-232C Port for DNC Interface
15" Color LCD Screen
Main & Subspindle Synchronization
All Available Manuals
Specifications
| Manufacturer | Mazak |
| Model | Integrex 200-IIIS |
| Year | 2004 |
| Condition | Used |
| Stock Number | 118103 |
| Machine Control | Mazatrol Fusion 640MT Pro |
| Chuck Sizes Main / Subspindle | 8" 3-Jaw Hydraulic both spindles |
| Maximum Swing | 26" |
| Maximum Turning Diameter | 26" for chucking |
| Distance Between Centers | 40" |
| X-Axis Travel | 22.83" |
| Y-Axis Travel | +/- 3.15" |
| Z-Axis Travel | 41.14" |
| W-Axis Travel | 41.34" (subspindle) |
| C-Axis Rotation | .0001 Degree - Both Spindle |
| B-Axis Tilt Movement | 225 Degrees |
| Spindle Nose / Bore / Bar Capacity | A2-6" / 2.99" / 2" |
| Spindle Speed | 5,000 RPM |
| Spindle Motor | 30 HP |
| Subspindle Speed | 5,000 RPM |
| Subspindle Motor | 25 HP |
| Milling Spindle Speed | 12,000 RPM |
| Milling Spindle Motor | 25 HP |
| Tool Magazine Capacity | 40 Station Tool Changer - KM63 |
| Rapid Traverse Rates (X, Y, Z) | 1496 IPM, 1024 IPM, 1496 IPM |
| Machine Dimensions LxWxH | 151" x 93" x 103" |
| Machine Weight | 28,700 lbs |
