2000 Okuma Crown L1060 BB
Vendido
2000 Okuma Crown L1060 BB
Ubicación:Ohio
Descripción
IGF Conversational Programming
Tailstock
Chip Conveyor
10" 3 Jaw Hydraulic Chuck
Mac Man
Inch/Metric Switchable
Big Bore Spindle Option
Heavy Duty Slant Bed Construction
160M Buffer
Hi-G Control
NC Turret
Turret Positioning Compensation
LAP 4
Nose-R 2B
Exp Auto Chamfer
Spindle Orientation
Animation
All Available Manuals
All Available Tool Holders
Wired 220V Electrics
15,372 Cutting Hours
Especificaciones
| Fabricante | Okuma |
| Modelo | Crown L1060 BB |
| Año | 2000 |
| Condición | Usado |
| Número de Stock | 117989 |
| Machine Control | Okuma OSP-U10L |
| Chuck Size | 10" 3-Jaw Hydrualic |
| Maximum Swing over Bed | 21.65" |
| Maximum Swing Over Cross Slide | 15.75" |
| Distance Between Centers | 20" |
| Maximum Turning Diameter | 10.63" |
| Maximum Turning Length | 19.68" |
| X-Axis Travel | 7.28" |
| Z-Axis Travel | 20.47" |
| Spindle Nose / Spindle Bore / Bar Capacity | A2-8" / 3.15" / 2.7" |
| Spindle Speed | 65 - 3,500 RPM |
| Spindle Motor | 20 HP |
| Number of Turret Positions | 12 Position Turret |
| Rapid Traverse Rates X/Z | 590 IPM / 787 IPM |
| Machine Dimensions LxWxH | 104"x74"x72" |
| Machine Weight | 10,000 lbs |
