2016 Mazak Variaxis J-600 5X
No longer available
2016 Mazak Variaxis J-600 5X
$274,500 (USD)
Location:Dundee, FL
Description
213 PSI Coolant thru the Spindle 30 Station Tool Changer with CAT #40 Taper Tool Length Measurement System Mist Collector Chip Conveyor Additional Work Light Work Setting Error Compensation Ethernet Port Interface All Available Manuals
Specifications
| Manufacturer | Mazak |
| Model | Variaxis J-600 5X |
| Year | 2016 |
| Condition | Used |
| Stock Number | 116873 |
| Quantity | 1 |
| Control | Mazatrol Matrix 2 |
| Table Size | 20" Diameter |
| Maximum Table Load | N/A |
| X-Axis Travel | 33.46" |
| Y-Axis Travel | 21.65" |
| Z-Axis Travel | 20.08" |
| B-Axis Tilt Movement | 210 Degrees |
| C-Axis Rotation | .0001 Degrees |
| Maximum Workpiece Diameter | 28.74" |
| Maximum Workpeice Height | 17.72" |
| Spindle Taper | CAT 40 |
| Spindle Speed | 12,000 RPM |
| Spindle Motor | 15 HP |
| Tool Magazine Capacity | 30 ATC |
| Maximum Tool Diameter / Length / Weight | 35.4" / 11.81" / 17.64 lbs |
| Machine Dimensions LxWxH | N/A |
| Machine Weight | 28,000 lbs |
