2010 Haas VF2SSYT
Sold
2010 Haas VF2SSYT
$42,500 (USD)
Location:New York, NY
Description
4th Axis Drive & Wiring BT 40 Spindle Taper Option Extended 20" Y Axis Travel Auger Style Chip Conveyor Programmable Coolant Nozzle 24 Station Side Mounted Tool Changer 55 Gallon Coolant Tank Rigid Tapping 1 MB Programming Memory Inline Direct Drive Spindle 15" Color LCD Monitor USB Port Interface RS 232 Port Interface All Available Manuals Wired 195/260V Electrics
Expected to be available at end July 2021
Specifications
| Manufacturer | Haas |
| Model | VF2SSYT |
| Year | 2010 |
| Condition | Used |
| Stock Number | 117482 |
| Quantity | 1 |
| Control | Haas 32 BIT |
| Table Size | 36" x 18" |
| Maximum Table Load | 1,500 lbs. |
| Distance Spindle Nose to Table Top | 4" - 24" |
| X-axis travel | 30" |
| Y-Axis Travel | 20" |
| Z-Axis Travel | 20" |
| Spindle Taper | BT #40 |
| Spindle Speeds | 12,000 RPM |
| Spindle Motor | 30 HP |
| Number of Tool Positions | 24 Position ATC - Side Mounted |
| Maximum Tool Diameter / Length / Weight | 5" / 11" / 12 lbs. |
| Tool Change Time Chip to Chip | 2.2 seconds |
| Rapid Traverse Rates | 1400 IPM |
| Cutting Feedrates | 833 IPM |
| Machine Dimensions | 95" x 89" x 94" |
| Machine Weight | 8,400 lbs. |
