2007 Haas SL-40 Big Bore Chucker
No longer available
2007 Haas SL-40 Big Bore Chucker
Location:Texas
Description
18" 3-Jaw Hydraulic Chuck Big Bore Spindle with 7.08" Bar Capacity Chip Conveyor Tool Presetter Ethernet/Hard Drive Intuitive Programming User Definable Macros Spindle Orientation High Intensity Lighting 2 Speed Gearbox Extra Performance Package with 55 HP Motor Color LCD Monitor All Available Manuals
Specifications
| Manufacturer | Haas |
| Model | SL-40 Big Bore Chucker |
| Year | 2007 |
| Condition | Used |
| Stock Number | 117405 |
| Quantity | 1 |
| Control | Haas 32 BIT |
| Chuck Size | 18" Hydraulic Chuck |
| Maximum Swing | 40" |
| Maximum Swing Over Cross Slide | 25" |
| Maximum Cutting Diameter | 25.5" |
| Maximum Bar Capacity | 6.5" |
| X-Axis Travel | 17" |
| Z-Axis Travel | 44" |
| Spindle Nose / Spindle Bore | A2-11" / 7.08" |
| Spindle Speed | 1,400 RPM |
| Spindle Motor | 55 HP |
| Number of Turret Positions | 10 Station Turret |
| Rapid Traverse Rates | 710 IPM |
| Machine Dimensions | 189.5" x 92" x 86" |
| Machine Weight | 25,000 lbs. |
