2022 Haas ST-10 Chucker, Tool Presetter, Chip Conveyor, Rigid Tapping 1GB Program Memory **Only 121 Run Time Hours**
2022 Haas ST-10 Chucker, Tool Presetter, Chip Conveyor, Rigid Tapping 1GB Program Memory **Only 121 Run Time Hours**
Contact us for price
Location:Texas
or
Call (863) 439-6066
Description
15" LCD Color Monitor
6.5" 3 Jaw Hydraulic Chuck
Royal Quick-Change Collet Chuck
Automatic Tool Presetter
Belt Type Chip Conveyor
Control Touch Screen
Ethernet Interfacxe
WIFI Early Power Failure Detection Module
Advanced Tool Management
Media Display M-Code M130
Haas Connect
Remote Monitoring
Safe Run
Haas Drop
1GB Program Memory
User Definable Macros
Visual Part Programming System
Rigid Tapping
All Available Manuals
**No Tailstock**
**Power On Hours 1,303**
**121 Cut Hours**
As Equipped new Price $80k
Specifications
| Manufacturer | Haas |
| Model | ST-10 Chucker, Tool Presetter, Chip Conveyor, Rigid Tapping 1GB Program Memory **Only 121 Run Time Hours** |
| Year | 2022 |
| Condition | Used |
| Stock Number | 120662 |
| Machine Control | Haas CNC Control |
| Chuck Size | 6.5" / 1.75" Thru hole |
| Maximum Swing | 25.25" |
| Maximum Swing Over Cross Slide | 16.25" |
| Maximum Machining Diameter | 14" |
| Maximum Machining Length | 14" |
| X-Axis Travel | 7.88" |
| Z-Axis Travel | 14" |
| Spindle Nose / Bore / Bar Capacity | A2-5" / 2.31" / 1.75" |
| Spindle Speeds | 6,000 RPM |
| Spindle Motor | 15 HP |
| Number of Turret Positions | 12 Bolt on Style Turret |
| Spindle Torque | 75 ft/lbs. |
| Rapid Traverse Rates | 1,200 IPM |
| Machine Dimensions LxWxH | 92"x55"x69" |
| Machine Weight | 6,420 lbs |
