2002 Milltronics ML-15
2002 Milltronics ML-15
Contact us for price
Location:Ohio
or
Call (863) 439-6066
Description
8" 3 Jaw Chuck
10" LCD Active Matrix Color Display
Tailstock
Electronic Hand Wheels for Manual Operation
Coolant System
Hardened / Ground Ways
220V 3-Phase
Specifications
| Manufacturer | Milltronics |
| Model | ML-15 |
| Year | 2002 |
| Condition | Used |
| Stock Number | 120548 |
| Machine Control | Milltronics Centurion 6 Control |
| Chuck Size | 8" 3-Jaw Manual |
| Maximum Swing over Bed | 15" |
| Maximum Swing Over Cross Slide | 7.8" |
| Distance Between Centers | 36" |
| X-Axis Travel | 7.5" |
| Z-Axis Travel | 36" |
| Subspindle Nose / Bore / Bar Capacity | D1-5 Camlock / 2.18" / |
| Spindle Speeds | 40- 3,000 RPM |
| Spindle motor | 7.5 HP |
| Turret Type | Alois Style Tool Post |
| Rapid Traverse Rates | 300 IPM |
| Tailstock Quill Diameter / Quill Travel / Taper | 1.875" / 5.5" / MT #4 |
| Machine Dimensions LxWxH | 96"x48"x72" |
| Machine Weight | 4,000 lbs |
