2004 Teknics MC-40V Fanuc 0M, 40"x20"x24", BT40 w/ Toolholders, CTS, 30 Station Sidemounted ATC
2004 Teknics MC-40V Fanuc 0M, 40"x20"x24", BT40 w/ Toolholders, CTS, 30 Station Sidemounted ATC
Contact us for price
Location:New Jersey
or
Call (863) 439-6066
Description
Coolant Through the Spindle
30 Station Side Mounted Tool Changer
Remote Jog Handle
Micro DNC2 Drip Feed Box
M Codes for using Haas 4th Axis Indexer Unit
Flood Coolant
Coolant System with Tank and Pump
RS 232 Port Interface
Wired 208/240V Electrics
Approximately (80) BT40 Tool Holders Included
Open Top Design Allowing for Overhead Crane Loading of Heavy Parts
Huge Interior Work Space
Heavy Duty Pre-Stressed Ball Screws
All Available Manuals
**One Owner Machine, Well Taken Care Of, VERY LOW HOURS**
**Draw Bar Recently Rebuilt**
**Optional Haas HRT-210 4th Axis Table and Haas Programming Box at Additional Cost**
Specifications
| Manufacturer | Teknics |
| Model | MC-40V |
| Year | 2004 |
| Condition | Used |
| Stock Number | 120545 |
| Machine Control | Fanuc 0M Control |
| Table size | 44.1" x 19.7" |
| X axis travel | 41.7" |
| Y axis travel | 20.1" |
| Z-axis travel | 24" |
| Spindle taper | BT 40 Taper |
| Spindle speed - 2 ranges | 8,000 RPM |
| Spindle motor 30 minutes / continuous | 30 HP / 25 HP |
| Number of tool positions | 30 Position Side Mount ATC |
| Machine dimensions | 112" x 100" x 113" approximate |
| Machine weight (approximately) | 18,000 lbs |
