2012 Kent ML-1740T Engine Lathe
2012 Kent ML-1740T Engine Lathe
Contact us for price
Location:Florida
or
Call (863) 439-6066
Description
10" 3-Jaw Manual Chuck
Steady Rest
Coolant System
Thread Chasing Dial
Work Light
Adjustable Over-Load Feed Clutches
Full-Length Safety Foot Brake
Spindle Jog Button Control
One-Shot Lubrication for Apron, Carriage & Bed Ways
Made in Taiwan
Specifications
| Manufacturer | Kent |
| Model | ML-1740T Engine Lathe |
| Year | 2012 |
| Condition | Used |
| Stock Number | 120421 |
| Maximum Swing over Bed | 17" |
| Maximum Swing Over Cross Slide | 11.875" |
| Maximum Swing over Gap | 24.5" |
| Distance Between Centers | 44" |
| Spindle Nose / Spindle Bore | D1-6 Camlock / 3.125" |
| Spindle Speeds | 12 Speeds 36 to 1,800 RPM |
| Spindle Motor | 7.5 HP 230V/460V 3-Phase |
| Tailstock Quill Travel | 5" |
| Tailstock Taper | #4MT |
| Inch Threads | 45, 2 to 72 TPI |
| Metric Threads | 39, .2 to 14mm |
| Machine Dimensions LxWxH | 89"x33"x58" |
| Machine Weight | 4,510 lbs |
| Number of Tool Positions | 4 Indexable |
