2014 Haas VF4 with Coolant Thru Spindle, 4th Axis Drive & Wiring, Prog. Coolant, Probe Ready, 20 Pos. Umbrella ATC
2014 Haas VF4 with Coolant Thru Spindle, 4th Axis Drive & Wiring, Prog. Coolant, Probe Ready, 20 Pos. Umbrella ATC
$39,500 (USD)
Location:Ohio
or
Call (863) 439-6066
Description
Haas Intuitive Probing Ready with Receiver ONLY - no probes
Coolant Through the Spindle - 300 PSI
Programmable Coolant Nozzle
Auger Style Chip Conveyor
Spindle Orientation
User Definable Macros
Coordinate Rotation & Scaling
Haas Intuitive Programming
Rigid Tapping
Internal High Voltage Isolated Transformer
USB Port Interface RS-232C Port Interface 15" LCD Color Monitor
Wired 360-480V Electrics
**Machine has ONLY cut aluminum**
Specifications
| Manufacturer | Haas |
| Model | VF4 |
| Year | 2014 |
| Condition | Used |
| Stock Number | 120264 |
| Control | Haas CNC Control |
| Table size | 52" x 18" |
| Maximum Weight on Table | 3,500 lbs. |
| X-Axis Travel | 50" |
| Y-Axis Travel | 20" |
| Z-Axis Travel | 25" |
| Spindle Taper | CAT #40 |
| Spindle Speeds | 0 - 8,100 RPM |
| Spindle Motor 30 Minutes/Continuous | 30 HP / 20 HP |
| Spindle Nose to Table Top | 4" - 29" |
| Number of Tool Positions | 20 Station ATC |
| Rapid Traverse Rates | 1000 IPM |
| Cutting Feedrates | 650 IPM |
| Machine Dimensions | 122" x 95" x 100" |
| Machine Weight | 13,300 lbs. |
