Trennjaeger Model PMC12 36" Semi-Automatic/Manual Circular Cold Saw

Machine Capacities

-Machine stand of solid steel construction.

- Planed machine table of high tensile strength steel.

- Cutting head unit adjustable dovetail guides.

- Gear box with large helical hardened gears.

- For segmental circular cold saw blade of 760mm (30") and 910mm (36") diameter.

- Fixture for chip remover.

- Adjustable blade stabilizer.

- Centralized lubrication system for guide tracks of cutting head carriage.

- Two-speed drive motor 6.1/7.5 HP, 1800/3600 RPM, with Vee-belt step pulley for 4 saw

blade periphery speeds 52/104 and 72/144 ft/min.

- Electrics upgraded to push buttons with contactors.

- Complete hydraulic system. Hydraulic motor, 4 HP, 1500 RPM, pump, pressure gauge and

thermo-magnetic motor protection switch.

- Complete coolant system with 0.2 HP motor and pump.

- Manual control valves for saw feed and vertical and horizontal clamping.

- Two vertical clamping cylinders with 12" stroke, adjustable longitudinally and one horizontal

clamping cylinder with 1½" stroke adjustable laterally.

- All hydraulic and electrical installations are easily accessible.

- Built-in tool and electrical cabinets.

- Machine finish - gray.

- Powered mitre turn table.

*Preliminary equipment descriptions are intended only as a guide, items of importance should be verified
