2022 Doosan Lynx 2100LYA w/ Full C Axis, Milling Capability, Long Bed, Chip Conveyor, Toolsetter
2022 Doosan Lynx 2100LYA w/ Full C Axis, Milling Capability, Long Bed, Chip Conveyor, Toolsetter
Contact us for price
Location:Mississippi
or
Call (863) 439-6066
Description
Full C-Axis Spindle Rotation
Live Milling/Drilling Capability
6" 3 Jaw Samcully Hydraulic Chuck - Brand New-Never held a part
Chip Conveyor
Auto Tool Presetter
Tailstock
Parts Catcher
165 PSI High Pressure Coolant
Coolant System with Tank & Pump
Machine Status Condition Lights
USB Port Interace
RS 2232 Port Interface
All Available Static Tooling
(2) Live Radial Holders
(1) Live Axial Holder
All Available Manuals
**Less than 1000 Spindle Run Hours**
**Used in manufacture of custom knives and pens**
**Client recently replaced this unit with a unit that has a subspindle on it**
Specifications
| Manufacturer | Doosan |
| Model | Lynx 2100LYA |
| Year | 2022 |
| Condition | Used |
| Stock Number | 120007 |
| Machine Control | Fanuc i Series |
| Chuck Size | 6" 3-Jaw Hydraulic |
| Maximum swing over bed | 23.6" |
| Maximum turning diameter | 11.8" |
| Maximum turning length | 20.1" |
| Maximum bar capacity | 2.00" |
| X-axis travel | 8.1" |
| Y-Axis Travel | +/- 2.5" |
| Z-axis travel | 22" |
| Spindle nose / spindle bore | A2-5" / 2.4" |
| Spindle Speed | 6,000 |
| Spindle motor | 20 HP |
| Number of Turret Positions | 12 Position Turret |
| Rotary Tool Speed / Rotary Motor | 6,000 rpm / 5 hp |
| Tailstock Quill Diameter / Quill Travel / Taper | 2.6" / 3.1" / #4 MT |
| Machine dimensions lxwxh | 114" x 67" x 76" |
| Machine weight | 8,500 lbs |
