2003 Omniturn GT-75 Series III with Barfeed, 5C Collet Closer, Gang Style Tool Slide
2003 Omniturn GT-75 Series III with Barfeed, 5C Collet Closer, Gang Style Tool Slide
$14,500 (USD)
Location:New York, NY
or
Call (863) 439-6066
Description
Omniturn OT CNC Control
Single Tube Bar Feeder
Pneumatic Collet Closer
Gang Style Tool Slide
Linear Guides
Coolant System
RS 232 Port Interface
All Available Manuals
Wired 220V , Three Phase Power
Specifications
| Manufacturer | Omniturn |
| Model | GT-75 Series III |
| Year | 2003 |
| Condition | Used |
| Stock Number | 120015 |
| Control | Omniturn OT CNC Control |
| Chuck Size | 5C Collet Nose |
| Maximum Cutting Diameter | .6" |
| X-Axis Travel | 12" |
| Z-Axis Travel | 9" |
| Spindle Nose / Bore / Bar Capacity | 5C w/4 Camlock / 1.125" / 1.06" |
| Spindle Speed | 4,000 rpm |
| Spindle Motor | 5 hp |
| Number of Tool Positions | Gang Style |
| Threading | 240 tpi to .5 tpi |
| Rapid Traverse Rates | 300 ipm |
| Machine Dimensions LxWxH | 34"x66"x75" |
| Machine Weight | 1,650 lbs |
