2023 Haas VF-2SS w/ Haas HRT-210 Rotary Table, Probing, High Speed Machining, Auger, Pcool
2023 Haas VF-2SS w/ Haas HRT-210 Rotary Table, Probing, High Speed Machining, Auger, Pcool
Contact us for price
Location:Tennessee
or
Call (863) 439-6066
Description
4th Axis Drive & Wiring
Haas HRT-210 4th Axis Rotary Table
WIPS Wireless Intuitive Probing System, Renishaw
30 Position Side Mounted Tool Changer
Auger Style Chip Conveyor
High-Speed Machining
Programmable Coolant Nozzle
Control Cabinet Cooler
Coordinate Rotation & Scaling
Visual Part Programming
Spindle Orientation
User Definable Macros
High-Intensity Lighting
Chip Tray Filter Kit
15" Color LCD Monitor
Ethernet Interface
USB Port Interface
RS 232C Port Interface for DNC Operation
Rigid Tapping
55 Gallon Coolant System with Tank & Pump
**Power On Hours 4,131**
**Cycle Start Hours 1,404**
**Feed Cutting Hours 1,157**
**Price New as Equipped at $114,155**
Specifications
| Manufacturer | Haas |
| Model | VF-2SS w/ Haas HRT-210 Rotary Table, Probing, High Speed Machining, Auger, Pcool |
| Year | 2023 |
| Condition | Used |
| Stock Number | 120003 |
| Table Size | 36" x 14" |
| Maximum Table Load | 1,500 lbs. |
| Spindle Nose to Table Top | 4" - 24" |
| X Axis Travel | 30" |
| Y Axis Travel | 16" |
| Z Axis Travel | 20" |
| Spindle Taper | CAT 40 |
| Spindle Speeds | 12,000 RPM |
| Spindle Motor | 30 HP - Direct Drive |
| Number of Tool Positions | 30 Station Side Mounted ATC |
| Rapid Traverse Rates (X, Y, Z) | 1400 IPM |
| Cutting Feedrates | 0.1 - 833 IPM |
| Machine Dimensions | 88" x 93" x 106" |
| Machine Weight | 9,000 lbs. |
