2012 Haas TL-2 with 3" Big Bore Option, Tailstock, 10" 3 Jaw Chuck, Tool Post, Chuck Guard, Manual Hand Wheels
2012 Haas TL-2 with 3" Big Bore Option, Tailstock, 10" 3 Jaw Chuck, Tool Post, Chuck Guard, Manual Hand Wheels
Contact us for price
Location:North Carolina
or
Call (863) 439-6066
Description
10" 3 Jaw Manual Chuck
3" Bar Capacity Option
Tool Post
Roll up Operator Cover
Tailstock
Coolant System with Tank & Pump
Manual Hand Wheels Integral Chip-Flow Channel Flip Down Safety Enclosure
USB Port Interface RS 232 Port Interface Vector Drive Spindle
Machine can be run at either 208V Three Phase or 240V Single Phase Power
Specifications
| Manufacturer | Haas |
| Model | TL-2 |
| Year | 2012 |
| Condition | Used |
| Stock Number | 119923 |
| Control | Haas CNC Control |
| Chuck Size | 10" 3 Jaw Chuck |
| Maximum Swing over Bed | 20" |
| Maximum Swing Over Cross Slide | 11" |
| Maximum Cutting Diameter | 16" |
| Maximum Machining Length | 48" |
| Maximum Bar Capacity | 3" |
| X-axis travel | 8" |
| Z-Axis Travel | 48" |
| Spindle Nose / Spindle Bore | A2-6" / 3.0" |
| Spindle Speeds | 1,800 RPM |
| Spindle Motor | 10 HP |
| Number of Turret Positions | Tool Post |
| Rapid Traverse Rates X/Z | 450 IPM / 450 IPM |
| Machine Dimensions | 100" x 55" x 80" |
| Machine Weight | 5,000 lbs. |
