2006 Kingston CL-38x2000 with 7.3" Bar Capacity, Steady Rest, Tailstock, Dual Turret Design
2006 Kingston CL-38x2000 with 7.3" Bar Capacity, Steady Rest, Tailstock, Dual Turret Design
$42,500 (USD)
Location:Oklahoma
or
Call (863) 439-6066
Description
24" 4 Jaw Air Chuck
7.3" Bar Capacity
Chip Conveyor
Tailstock
Steady Rest
Remote Jog Handle
RS 232 Port Interface
Coolant System
All Available Manuals
All Available Tool Holders
Specifications
| Manufacturer | Kingston |
| Model | CL-38x2000 |
| Year | 2006 |
| Condition | Used |
| Stock Number | 119749 |
| Machine Control | Fanuc Oi-TC |
| Chuck Size | 24" 4-Jaw Air Chuck |
| Maximum Swing | 26" |
| Maximum Swing Over Cross Slide | 14.6" |
| Maximum Cutting Diameter | 23.6" |
| Distance Between Centers | 78" |
| X-axis travel | 21.6" |
| Z-Axis Travel | 76.8" |
| Spindle Speeds | 3 - 2,000 RPM |
| Spindle Motor | 30 HP |
| Spindle Nose | A2-11" |
| Spindle Bore | 7.3" |
| Number of Turrets | 2 Turrets |
| Number of Turret Positions | 8 Vertical Front / 6 Horizontal Rear |
| Rapid Traverse Rates | 394 ipm |
| Tailstock Quill Diameter / Quill Travel / Taper | 5.9" / 8.6" / #5 MT |
| Machine Dimensions LxWxH | 273"x91"x79" |
| Machine Weight | 17,857 lbs |
