2002 Haas VF-4
No longer available
2002 Haas VF-4
$17,500 (USD)
Location:Ontario, Canada
Description
4th Axis Drive & Wiring
24 Station Side Mounted Tool Changer
Programmable Coolant Nozzle
Auger Style Chip Conveyor
2 Speed Gearbox
1 MB Extended Program Memory
Remote Jog Handle
Visual Quick Code Programming
Spindle Orientation
Coordinate Rotation & Scaling
User Definable Macros
3.5" Floppy Disk Drive
RS-232C Port Interface
Chip Pan with Coolant Pump
Wired 208/230V Electrics All Available Manuals
Specifications
| Manufacturer | Haas |
| Model | VF4 |
| Year | 2001 |
| Condition | Used |
| Stock Number | 119716 |
| Control | Haas CNC Control |
| Table size | 52" x 18" |
| Maximum Weight on Table | 3,500 lbs. |
| X-Axis Travel | 50" |
| Y-Axis Travel | 20" |
| Z-Axis Travel | 25" |
| Spindle Taper | CAT #40 |
| Spindle Speeds | 0 - 7,500 RPM |
| Spindle Motor | 20 HP - 2 Speed Geared |
| Spindle Nose to Table Top | 4" - 29" |
| Number of Tool Positions | 24 Station Side Mounted ATC |
| Maximum Tool Diameter / Length / Weight | 5" / 13" / 12 lbs. |
| Rapid Traverse Rates | 1,000 IPM |
| Cutting Feedrates | 500 IPM |
| Machine Dimensions | 122" x 95" x 100" |
| Machine Weight | 13,300 lbs. |
