2007 Mori Seiki NH-4000 DCG Fanuc MSX-701 II
2007 Mori Seiki NH-4000 DCG Fanuc MSX-701 II
Contact us for price
Location:Illinois
or
Call (863) 439-6066
Description
Mori MAPPS Conversational Programming
48 Work Offsets
Custom Macro B
1,000 PSI Coolant Thru the Spindle
Extended Part Program Editing
High Speed Skip Ahead
Rigid Tapping
Helical Interpolation
60 ATC
1,000 psi Chip Blaster
Chip Conveyor
Specifications
| Manufacturer | Mori Seiki |
| Model | NH-4000 DCG Fanuc MSX-701 II |
| Year | 2007 |
| Condition | Used |
| Stock Number | 119669 |
| Machine Control | Mori Fanuc MSX 701 II Color |
| Pallet size / number of pallets | 15.7"x15.7"/2 plts. |
| Table indexing | 1 Degree Rotary |
| Table load capacity | 1,100 lbs. |
| X-axis travel | 22.04" |
| Y-axis travel | 22.04" |
| Z-axis travel | 24.8" |
| Spindle nose | CAT # 40 |
| Spindle speeds | 14,000 RPM |
| Spindle motor 30 min. / cont. | 25 HP / 20 HP |
| Tool magazine capacity | 60 Position ATC |
| Max. tool diam./length/weight | 5.9"/14.2"/26.4 lbs. |
| Tool change time-tool to tool | 1.3 seconds |
| Rapid traverse rates | 1969 IPM |
| Machine dimensions | 90.6"x148"x88.4" |
| Machine weight | 21,340 lbs. |
