2008 Haas EC-1600-4X 4 Axis Horizontal Machining Center

2008 Haas EC-1600-4X 4 Axis Horizontal Machining Center

Contact us for price

Location:North Carolina

orCall (863) 439-6066

Description

Built in Full 4th Axis Rotary Platter Within Table

WIPS Haas Renishaw Wireless Intuitive Probing System

1,000 PSI Coolant Thru the Spindle

10,000 RPM Spindle Option

4th & 5th-Axis Drive

50 Station Tool Changer

Dual Chip Augers

High-Speed Machining

Programmable Coolant Nozzle

Spindle Orientation

Visual Quick Code Programming System

Coordinate Rotation & Scaling

Haas Intuitive Programming System

Second Home Position

2 Speed Geared Headstock

16 MB Expanded Program Memory

Linear Scales

Rigid Tapping

Auxiliary Coolant Filter System

95 Gallon Coolant Tank

8 Spare M Functions

Color LCD Remote Jog Handle

Power Failure Detection Module

Memory Lock Keyswitch

Extended Anchor Kit

Conversion Box BL to Brush Drive 17 Pin

15" Color LCD Monitor

Ethernet Interface

USB Port Interface

RS 232 Port Interface


**HRT-310 Rotary Table w/Tailstock for an additional $12k**

**Manufactured New in October of 2008, delivered in 2009**

**Used in High-End racing facility, never has seen production work**

Specifications

ManufacturerHaas
ModelEC-1600-4X
Year2008
ConditionUsed
Stock Number119674
Table Size64" x 36"
Maximum Table Load10,000 lbs
X-axis travel64"
Y-Axis Travel40"
Z-Axis Travel32"
Spindle TaperCAT 50
Spindle Speed10,000 RPM
Spindle Motor30 HP - 2 Speed Geared Head
Tool Magazine Capacity50 Station Tool Changer
Rapid Traverse Rates540 IPM
Maximum Tool Diameter / Length / Weight10" / 20" / 30 lbs
Electrics208/230V 3-ph / 80 amps
Machine Dimensions LxWxH190"x144"x135"
Machine Weight30,000 lbs
