2017 Haas ST-10 w/ Tailstock, Chip Conveyor, Tool Presetter, Both 6.5" Hydraulic and Collet Chuck
No longer available
2017 Haas ST-10 w/ Tailstock, Chip Conveyor, Tool Presetter, Both 6.5" Hydraulic and Collet Chuck
Location:California
Description
6.5" 3 Jaw Hydraulic Chuck
Collet Chuck
Automatic Tool Presetter
Belt Type Chip Conveyor
Tailstock
User Definable Macros
Rigid Tapping
15" LCD Color Monitor
Complete Coolant System with Tank & Pump
USB Port Inteface
RS 232 Port Interface
All Available Manuals
Miscellaneous OD & ID Tool Holders
Specifications
| Manufacturer | Haas |
| Model | ST-10 |
| Year | 2017 |
| Condition | Used |
| Stock Number | 119549 |
| Machine Control | Haas CNC Control |
| Chuck Size | 6.5" / 1.75" Thru hole |
| Maximum Swing | 25.25" |
| Maximum Swing Over Cross Slide | 16.25" |
| Maximum Machining Diameter | 14" |
| Maximum Machining Length | 14" |
| X-Axis Travel | 7.88" |
| Z-Axis Travel | 14" |
| Spindle Nose / Bore / Bar Capacity | A2-5" / 2.31" / 1.75" |
| Spindle Speeds | 6,000 RPM |
| Spindle Motor | 15 HP |
| Number of Turret Positions | 12 Bolt on Style Turret |
| Spindle Torque | 75 ft/lbs. |
| Rapid Traverse Rates | 1,200 IPM |
| Machine Dimensions LxWxH | 92"x55"x69" |
| Machine Weight | 6,420 lbs |
