2016 Mazak Nexus HCN 4000-III

2 Pallet Factory Changer

NC Rotary Table 0.001 Degree (360,000 Positions)

60 Station Tool Changer

High Pressure Coolant Through the Spindle - 213 PSI

Chip Conveyor - Consep-1

Automatic Tool Length Measurement Probe

Tool Breakage Detection

18,000 RPM Spindle

Manual Pulse Generator

Cylindrical Interpolation

EIA/ISO Code Input Function

Additional EIA/ISO Functions

EIA Pattern Cycle

Flood Coolant System

Niagara Coolant

Air Through Spindle

Synchronous Tapping

Mazak Tapping/Boring Tornado (Mazatrol & EIA/ISO)

Inverse Time Feed

Sequence Number Comparison Stop Function

Thread Cutting Function

Backround Tool Path Check

Additional Workpiece Coordinate System-300 Pairs

Spindle Chiller Unit

Absolute Positioning System

LAN Port Interface

USB Port Interface

RS 232 Port Interface

Multi Tap Transformer

Relocation Detector

All Available Manuals

**Machine has ONLY cut aluminum**

The 2016 Mazak Nexus HCN 4000-III is a reliable used CNC horizontal machining center recognized for its robust capacity and precision. Equipped with the Mazatrol Matrix Nexus 2 Control, this machine ensures user-friendly operation and enhanced productivity. It features a dual pallet system, each measuring 15.7"x15.7", with a robust maximum table load capacity of 880 lbs, making it suitable for handling substantial workpieces. The machining center boasts impressive axis travel with 22.05" in X, and 25.2" in both Y and Z axes, providing ample versatility for complex tasks. It supports a spindle taper of #40 and operates at speeds up to 18,000 rpm, powered by a 25 HP motor, ensuring efficient and precise machining processes. The tool magazine holds up to 60 tools, accommodating up to 6.7" in diameter, 14.17" in length, and weights of 26.5 lbs, facilitating a wide range of machining operations. The machine has rapid traverse rates of 2,362 IPM, optimizing cycle times and productivity. Its dimensions are 207" x 87" x 106.8", and it weighs approximately 23,584 lbs, reflecting its solid construction. Overall, the Mazak Nexus HCN 4000-III is designed to meet rigorous manufacturing demands with precision and efficiency.
