2020 Haas Mini Mill
![Used 2020 Haas Mini Mill](https://i.machineryhost.com/a5771bce93e200c36f7cd9dfd0e5deaa/14952688aa8b8f0a7b60844561cd82bc/large-used-2020-haas-mini-mill.jpg)
2020 Haas Mini Mill
Contact us for price
Location:Illinois
orCall (863) 439-6066
Description
1 MB Memory
Rigid Tapping
Programmable Coolant
USB
15" Color LCD Control
**Low Hours**
Specifications
Manufacturer | Haas |
Model | Mini Mill |
Year | 2020 |
Condition | Used |
Stock Number | 119402 |
Table Size | 36" x 12" |
Maximum Table Load | 500 lbs |
X-axis travel | 16" |
Y-Axis Travel | 12" |
Z-Axis Travel | 10" |
Spindle Taper | CAT #40 |
Spindle Speed | 6,000 RPM |
Spindle Motor | 7.5 HP |
Distance Spindle Nose to Table Top | 4" - 14" |
Tool Magazine Capacity | 10 Position ATC |
Tool Change Time Tool to Tool | 2.5 Seconds |
Maximum Tool Diameter / Length / Weight | 3.5" / Na / Na |
Rapid Traverse Rates | 650 IPM |
Cutting Feedrates | 500 IPM |
Machine Dimensions LxWxH | 78" x 72"x85" |
Machine Weight | 4,100 lbs |
