2020 Haas UMC-750SS
2020 Haas UMC-750SS
$139,500 (USD)
Location:Florida
orCall (863) 439-6066
Description
Trunnion Style 5th Axis Table
Coolant Through the Spindle - 300 PSI
15,000 RPM Spindle
Haas Wireless Probing Package
Chip Conveyor
High-Speed Machining
Programmable Coolant Nozzle
User Definable Macros
Coordinate Rotation & Scaling
M19 Spindle Orientation
Haas Visual Programming System
Rigid Tapping
VPS Editing
1GB Memory
Wireless Networking
Compensation Tables
USB Port Interface
RS 232 Port Interface
Coolant System with Tank & Pump
All Available Manuals
**$6k aftermarket coolant system**
**Price as equipped today at $232,000, with current discounting at $201,260**
Specifications
| Manufacturer | Haas |
| Model | UMC-750SS |
| Year | 2020 |
| Condition | Used |
| Stock Number | 119229 |
| Table size | 19.7" x 24.8" |
| Table load capacity | 660 lbs |
| X axis travel | 30" |
| Y axis travel | 20" |
| Z axis travel | 20" |
| B axis rotate of trunnion | -35 Degrees to 110 Degrees |
| C axis table rotation | .001 Degree Positioning |
| Spindle taper | CAT #40 |
| Spindle speed | 15,000 RPM |
| Spindle motor | 30 HP |
| Distance Spindle Nose to Table Top | 4" - 24" |
| Tool magazine | 40 + 1 Position Toolchanger |
| Maximum Tool Diameter / Length / Weight | 5" / 12" / 12 lbs. |
| Rapid traverse rates | 1200 IPM |
| Maximum feed rates | 650 IPM |
| Machine dimensions | 157" x 94" x 101" |
| Machine weight | 19,100 lbs |
