2011 Haas VF1
No longer available
2011 Haas VF1
$29,950 (USD)
Location:Oklahoma
Description
2 Speed Geared Transmission
Coolant Through the Spindle - 300 PSI
Haas Wireless Intuitive Probing System
Spindle Orientation
Coordinate Rotation & Scaling
Haas Intuitive Programming System
User Definable Macros
4th Axis Drive & Wiring
Auger Style Chip Conveyor
Internal High Voltage Transformer
RS 232 Port Interface Complete Coolant System with Tank & Pump Rigid Tapping All Available Manuals
Wired 360V/480V Electrics
Specifications
| Manufacturer | Haas |
| Model | VF1 |
| Year | 2011 |
| Condition | Used |
| Stock Number | 119166 |
| Control | Haas CNC Control |
| Table Size | 26" x 14" |
| Maximum Table Load | 1,000 lbs |
| X-Axis Travel | 20" |
| Y-Axis Travel | 16" |
| Z-Axis Travel | 20" |
| Spindle Speed | 8,100 RPM |
| Spindle Taper | CAT 40 |
| Spindle Motor | 20 HP |
| Distance Spindle Nose to Table Top | 4" to 24" |
| Tool Magazine Capacity | 20 Position ATC - Umbrella Style |
| Rapid Traverse Rates | 1,000 IPM |
| Maximum Tool Diameter / Length / Weight | 3.5"/ NA / 12 lbs |
| Machine Dimensions LxWxH | 88"x96"x104" |
| Machine Weight | 7,500 lbs |
