2015 Doosan Puma 400XLMC
No longer available
2015 Doosan Puma 400XLMC
$229,500 (USD)
Location:Louisiana
Description
Extra Long Bed Design
Full C Axis Spindle Rotation
Live Milling/Drilling Capability
Chip Conveyor 18" Samchully 3 Jaw Hydraulic Chuck Programmable Tailstock
SMW Hydraulic Steady Rest 3.5" Floppy Disk Interface RS 232 Port Interface Coolant System with Tank & Pump
Boxed Way Construction on Slant Bed All Available Static Tooling
(5) Live Toolholders All Available Manuals
**Machine is currently be moved from current South Korea location to Louisiana, USA port**
Specifications
| Manufacturer | Doosan |
| Model | Puma 400XLMC |
| Year | 2015 |
| Condition | Used |
| Stock Number | 119102 |
| Control | Fanuc 32iB |
| Chuck Size | 18" Hydraulic Chuck |
| Maximum Swing | 30.31" |
| Maximum Turning Diameter | 20.05" |
| Maximum Turning Length | 120.85" |
| Maximum Bar Capacity | 6.5" |
| X-Axis Travel | 14.25" |
| Z-Axis Travel | 120" |
| Spindle Nose / Spindle Bore | A2-15" / 7.1" |
| Spindle Speeds | 1 -1500 RPM |
| Spindle Motor | 50 HP |
| Number of Turret Positions | 12 Position Turret |
| Rapid Traverse Rates X/Z | 630 IPM / 790 IPM |
| Tailstock Quill Diameter / Center | 4.7" / MT #5 |
| Tailstock Quill Travel | 4.7" |
| Machine Dimensions | 236" x 94" x 89" |
| Machine Weight | 35,000 lbs. |
