2008 Makino E33
2008 Makino E33
Contact us for price
Location:Illinois
or
Call (863) 439-6066
Description
Windows CE Graphical user Interface (GUI) Touch Screen
Probe Ready
Blum Laser
Graphite Machining Package
Auto Lube
Rigid Tapping
Helical Interpolation
Data Center for Networking and Storage Capability
Transformer
Spindle Chiller Unit
Linear Scale Feedback
Recent new Ballscrews
**Makino did all the Preventative Maintenance and Repairs
**Every 2,000 hours the Machine is completely gone through which takes two to three days.
**Machine was holding 0.0003" to 0.0005" when it was taken out of service on June 5, 2024.
Specifications
| Manufacturer | Makino |
| Model | E33 |
| Year | 2008 |
| Condition | Used |
| Stock Number | 119047 |
| Machine Control | Pro 5 |
| Table Size | 35.5" x 19.7" |
| Maximum Weight on Table | 1,102 lbs |
| X-Axis Travel | 25.6" |
| Y-Axis Travel | 17.7" |
| Z-Axis Travel | 17.7" |
| Spindle Taper | HSK E32 |
| Spindle Speeds | 400-40,000 rpm |
| Spindle Motor | 18.5 HP |
| Tool Magazine Capacity | 30 Station Side Mounted Tool Changer |
| Rapid Traverse Rates | 1,574 IPM |
| Machine Dimensions LxWxH | 90"x99"x119" |
| Machine Weight | 16,090 lbs |
