2007 Haas OL-1
No longer available
2007 Haas OL-1
$17,950 (USD)
Location:New York, NY
Description
Gang-Style Tooling
5C Pneumatic Collet Chuck
RS-232C Port Interface
Visual Quick Code Programming
Standard C Axis w/ Orientation
Coolant Pump & Tank
Full Enclosure
Ultra-Compact Size
1 MB Program Memory
Direct-Coupled Servo Motors
Wired Single Phase Power 240V
Specifications
| Manufacturer | Haas |
| Model | OL-1 |
| Year | 2007 |
| Condition | Used |
| Stock Number | 118742 |
| Chuck Size | 5C Collet |
| Maximum Swing Over Cross Slide | 11" |
| Maximum Machining Diameter | 4.95" |
| Maximum Machining Length | 8" |
| X-Axis Travel | 12" |
| Z-Axis Travel | 8" |
| Spindle Nose / Spindle Bore / Bar Capacity | Threaded 5C / 1.25" / 1.06" |
| Spindle Speed | 6,000 RPM |
| Spindle Motor | 5 HP |
| Turret Type | Gang Style |
| Rapid Traverse Rates | 757 IPM |
| Machine Dimensions LxWxH | 73"x43"x79" |
| Machine Weight | 1,300 lbs |
