2020 Haas VF2
No longer available
2020 Haas VF2
$59,950 (USD)
Location:Ontario, Canada
Description
Prepped for Coolant Through the Spindle
10,000 RPM Spindle
Chip Auger
Rigid Tapping
Programmable Coolant Nozzle
Wired for 4th Axis - Brushless Type
High Speed Machining
User Definable Macros
Haas Visual Parts Programming System
1 GB Programming Memory
Spindle Orientation
Work Light
Haas Connect
Media Display
Wifi Connect
Ethernet Interface
USB Port Interface
RS 232 Port Interface
Wired 220V Electrics
**Price out new as equipped at $80,855**
Specifications
| Manufacturer | Haas |
| Model | VF2 |
| Year | 2020 |
| Condition | Used |
| Stock Number | 118428 |
| Table Size | 36"x18" |
| Maximum Table Load | 3,000 lbs |
| X-axis travel | 30" |
| Y-Axis Travel | 16" |
| Z-Axis Travel | 20" |
| Distance Spindle Nose to Table Top | 4" - 24" |
| Spindle Taper | CAT 40 |
| Spindle Speed | 10,000 RPM |
| Spindle Motor | 30 HP |
| Tool Magazine Capacity | 20 Station Umbrella Type ATC |
| Rapid Traverse Rates | 1,000 IPM |
| Machine Dimensions LxWxH | 110"x93"x105" |
| Machine Weight | 8,600 lbs |
