2018 Haas DM-2

No longer available

2018 Haas DM-2

$87,500 (USD)

Location:Texas

Description

300 PSI Coolant Through the Spindle

4th Axis Drive & Wiring

Pneumatic Tailstock 4" Center Height

Manual Draw Tube 1.1" Through Hole

Programmable Coolant Nozzle

Haas WIPS Probing Package (Wireless Intuitive Probing System)

Chip Auger

15,000 RPM Spindle Option

Spindle Orientation

User Definable Macros

Coordinate Rotation & Scaling

Visual Part Programming System

High Speed Machining

2nd Home Position

Rigid Tapping Early Power Failure Detection Module Control Touch Screen 55 Gallon Coolant Tank

Anchor Kit

Enclosure Exhaust System

Wired 220V Electrics / 3 Phase

Power On Hours 3,724

Servo On Time 2,517

Cycle Start Time 1,584

Spindle On Time 1,530


**Manufactured new in July of 2018, delivered in early 2019**

**Machine was primarily used on plastic and aluminum**

**Price New As Equipped at nearly $100,000**

**Haas Dual 5C Indexer Unit is NOT included in Price**

Specifications

ManufacturerHaas
ModelDM-2
Year2018
ConditionUsed
Stock Number118343
ControlHaas CNC Control
Table Size34" x 15"
Maximum Table Load250 lbs
X-Axis Travel28"
Y-Axis Travel16"
Z-Axis Travel15.5"
Subspindle Speed15,000 RPM
Spindle TaperCAT 40
Spindle Motor15 HP
Rapid Traverse Rates2,400 IPM
Tool Magazine Capacity18+1 Station Side Mounted ATC
Machine Dimensions LxWxH91" x 100" x 98"
Machine Weight5,350 lbs
