2018 Haas VF2SS YT
No longer available
2018 Haas VF2SS YT
$79,950 (USD)
Location:California
Description
30+1 Position Side Mounted Tool Changer
Haas Wireless Probing Tool & Part Probing - Renishaw
300 PSI Coolant Through the Spindle
Auxiliary Coolant Filter System
15,000 RPM Spindle Option
Auger Style Chip Conveyor
Programmable Coolant Nozzle
Spindle Orientation
User Definable Macros
Coordinate Rotation & Scaling
Visual Programming System
High Intensity Lighting
Coolant System with Tank & Pump
RS 232C Port Interface for DNC Operation
All Available Manuals
Wired 220V Electrics
Specifications
| Manufacturer | Haas |
| Model | VF2SS YT |
| Year | 2018 |
| Condition | Used |
| Stock Number | 118319 |
| Pallet Size / Number of Pallets | 36" x 18" |
| Max table load | 1,500 lbs |
| X axis travel | 30" |
| Y axis travel | 20" |
| Z axis travel | 20" |
| Spindle taper | CAT #40 |
| Spindle speed | 15,000 RPM |
| Spindle motor | 30 HP - Direct Drive |
| Spindle nose to table top | 4" - 24" |
| Number of tool positions | 30 + 1 Position Side Mount |
| Max tool weight | 12 lbs. |
| Rapid feed rate (x,y,z) | 1,400 IPM |
| Cutting feed rate | 0.1 - 833 IPM |
| Machine dimensions | 106" x 101" x 101 " |
| Machine weight (approximately) | 9,500 lbs. |
