2008 Manford CB-410 Bed Mill
No longer available
2008 Manford CB-410 Bed Mill
$12,500 (USD)
Location:New Jersey
Description
Conversational Programming
Remote Jog Handle
Manual Hand Wheels (Y axis missing handle)
RS 232 Port Interface
Coolant Protection Covers
Lube System
Coolant Collection Pan
Boxed Ways
All Available Manuals
Leveling Pads
Specifications
| Manufacturer | Manford |
| Model | CB-410 CNC Bed Mill |
| Year | 2008 |
| Condition | Used |
| Stock Number | 118264 |
| Machine Control | Anilam 3000M |
| Table Size | 50" x 15" |
| Maximum Table Load | 660 lbs. |
| X-Axis Travel | 37.4" |
| Y-Axis Travel | 20" |
| Z-Axis Travel - Head Slide Travel | 18" |
| Quill Stroke | 5.51" |
| Distance Spindle Nose to Table Top | 5.5" - 23.6" |
| Swivel Angle of Head (Right and Left) | 45 Degrees |
| Distance from Spindle Center to Column Front Surface | 19.3" |
| Spindle Taper | NST #40 |
| Spindle Speeds | 50 - 3,600 RPM |
| Spindle Motor | 7.5 HP |
| Rapid Traverse Rates | 200 IPM |
| Cutting Feedrates | 110 IPM |
| Machine Dimensions | 70.5" x 88" x 96" |
| Machine Weight | 6,820 lbs. |
