2014 Haas EC-1600YZT
No longer available
2014 Haas EC-1600YZT
$179,500 (USD)
Location:California
Description
Full 4th Built in Rotary Platter with 5 Degree Index
Wireless Intuitive Probing System
Coordinate Rotation & Scaling
Spindle Orientation
User Definable Macros
1,000 PSI Coolant thru the Spindle
Remote Jog Handle w/ Color LCD
Dual Augers
Chip Conveyor
Programmable Coolant Nozzle
2 Speed Gearbox
Haas Intuitive Programming
Internal High Voltage Isolated Transformer
Haas CNC Control Cabinet Cooler
15" Color LCD Monitor
USB Port Interface
RS 232 Port Interface
Rigid Tapping
Memory Lock Keyswitch
New in April of 2014
*Machine is in a plant under power and able to be inspected.
Specifications
| Manufacturer | Haas |
| Model | EC-1600YZT |
| Year | 2014 |
| Condition | Used |
| Stock Number | 118211 |
| Table Size | 64" x 36" |
| Maximum Table Load | 10,000 lbs |
| B-Axis Table Rotation | 5 Degree |
| X-axis travel | 64" |
| Y-Axis Travel | 50" |
| Z-Axis Travel | 40" |
| Spindle Taper | CAT 50 |
| Spindle Speed | 6,000 RPM |
| Spindle Motor | 30 HP 2-Speed Geared Head |
| Tool Magazine Capacity | 50 Position Tool Changer |
| Rapid Traverse Rates | 540 IPM |
| Maximum Tool Diameter / Length / Weight | 10" / 20" / 30 lbs |
| Machine Dimensions LxWxH | 190"x144"x135" |
| Machine Weight | 35,000 lbs |
