2008 Haas Mini Mill
No longer available
2008 Haas Mini Mill
$26,500 (USD)
Texas
Description
10 Station Tool Changer
Direct Belt Drive
RS 232 Port Interface
Accepts 240V Single Phase or 208V Three Phase Power
Power On Hours 22,950
Approximate Spindle Hours 8,000
Specifications
Manufacturer | Haas |
Model | Mini Mill |
Year | 2008 |
Condition | Used |
Stock Number | 118180 |
Table Size | 36" x 12" |
Maximum Table Load | 500 lbs |
X-axis travel | 16" |
Y-Axis Travel | 12" |
Z-Axis Travel | 10" |
Spindle Taper | CAT #40 |
Spindle Speed | 7,500 RPM |
Spindle Motor | 7.5 HP |
Distance Spindle Nose to Table Top | 4" - 14" |
Tool Magazine Capacity | 10 Position ATC |
Tool Change Time Tool to Tool | 2.5 Seconds |
Maximum Tool Diameter / Length / Weight | 3.5" / Na / Na |
Rapid Traverse Rates | 650 IPM |
Cutting Feedrates | 500 IPM |
Electrical Requirements | 208V 3PH / 240V 1PH |
Machine Dimensions LxWxH | 78" x 80" x 98" |
Machine Weight | 3,400 lbs |
