2006 Haas SL-40LB
No longer available
2006 Haas SL-40LB
California
Description
18" Chuck
Hydraulic Steady Rest
Chip Conveyor
Rear Chuck Enclosure Extra Performance Package with 55 HP Spindle Motor
Fully Programmable Tailstock
Remote Jog Handle
Spindle Orientation
Visual Quick Code Programming
User Definable Macros
Early Power Failure Detection Module 2 Speed Geared Headstock
RS 232 Port Interface All Available Manuals
All Available Tool Blocks
Specifications
| Manufacturer | Haas |
| Model | SL-40LB |
| Year | 2006 |
| Condition | Used |
| Stock Number | 118051 |
| Control | Haas 32 BIT |
| Maximum Swing | 40" |
| Maximum Swing Over Cross Slide | 25" |
| Maximum Cutting Diameter | 25.5" |
| Maximum Cutting Length | 80" |
| Maximum Distance Between Centers | 81" |
| Maximum Bar Capacity | 6.5" |
| X-Axis Travel | 17" |
| Z-Axis Travel | 80" |
| Spindle Nose / Spindle Bore | A2-11" / 7.0" |
| Spindle Speeds | 1,400 RPM |
| Spindle Motor | 55 HP |
| Number of Turret Positions | 10 Station Turret |
| Rapid Traverse Rates | 710 IPM |
| Tailstock Body Travel / Tailstock Taper | 74" / MT #5 |
| Machine Dimensions | 195" x 102" x 89" |
| Machine Weight | 27,000 lbs. |
