1997 Hyundai Hit-15S
No longer available
1997 Hyundai Hit-15S
$10,500 (USD)
Location:Mississippi
Description
Tailstock w/Programmable Quill
Chip Conveyor
Coolant System
RS-232 Port
Automatic Tool Eye
All Available Manuals
Specifications
| Manufacturer | Hyundai |
| Model | Hit-15S |
| Year | 1997 |
| Condition | Used |
| Stock Number | 117899 |
| Machine Control | Siemens 840C |
| Chuck Size | 8" 3-Jaw Hydraulic |
| Maximum Swing | 17.32" |
| Maximum Cutting Diameter | 11" |
| Maximum Cutting Length | 19.69" |
| X-axis travel | 7.09" |
| Z-Axis Travel | 20.08" |
| Spindle Nose / Bore / Bar Capacity | A2-6 / 2.44" / 2" |
| Spindle Speeds | 45-4,500 rpm |
| Spindle Motor 30 Minutes/Continuous | 20 HP / 15 HP |
| Number of Turret Positions | 8 Pos |
| Rapid Traverse Rates | 1181 IPM |
| Tailstock Body Travel / Quill Travel | 18.9" / 5.12" |
| Machine Dimensions LxWxH | 101"x64"x72" |
| Machine Weight | 9,600 lbs |
