2013 Haas VM-6
No longer available
2013 Haas VM-6
$109,500 (USD)
Location:California
Description
Haas Wireless Intuitive Probing System
Through the Spindle Coolant READY only
24 Station Side Mounted Tool Changer
Chip Auger
High Speed Machining
Coordinate Rotation & Scaling
User Definable Macros
Spindle Orientation
Visual Programming System Editing
Media Display
Compensation Tables
Rigid Tapping
Remote Jog Handle
Ethernet Interface
USB Port Interface
RS 232 Port Interface
195/260V 3-Phase Power
All Available Manuals
Cycle Start Hours 6,203
Feed Cut Hours 5,590
Specifications
| Manufacturer | Haas |
| Model | VM-6 |
| Year | 2013 |
| Condition | Used |
| Stock Number | 117866 |
| Machine Control | Haas 32 BIT |
| Table size | 64" x 28" |
| Maximum Table Load | 4,000 lbs |
| X-Axis Travel | 64" |
| Y-Axis Travel | 32" |
| Z-Axis Travel | 30" |
| Spindle Taper | CAT 40 |
| Spindle Speeds | 12,000 RPM |
| Spindle Motor | 30 HP |
| Distance Spindle Nose to Table Top | 4" - 34" |
| Tool Magazine Capacity | 24 Position Side Mount |
| Rapid Traverse Rates X, Y / Z | 540 ipm, 540 ipm / 600 ipm |
| Machine Dimensions LxWxH | 135" x 178" x 129" |
| Machine Weight | 22,850 lbs |
