2011 Haas VF4
No longer available
2011 Haas VF4
$42,900 (USD)
Location:Minnesota
Description
Coolant Through the Spindle
4th Axis Wired
Highs Speed Machining
Auger Style Chip Conveyor
Programmable Coolant Nozzle
Remote Jog Handle
High Intensity Lighting
USB Port Interface RS-232C Port Interface 15" LCD Color Monitor
Coolant System with Tank & Pump All Available Manuals
Approximately 2500 Spindle Hours
Specifications
| Manufacturer | Haas |
| Model | VF4 |
| Year | 2011 |
| Condition | Used |
| Stock Number | 117014 |
| Control | Haas 32 BIT |
| Table size | 52" x 18" |
| Maximum Weight on Table | 3,500 lbs. |
| X-Axis Travel | 50" |
| Y-Axis Travel | 20" |
| Z-Axis Travel | 25" |
| Spindle Taper | CAT #40 |
| Spindle Speeds | 0 - 8,100 RPM |
| Spindle Motor 30 Minutes/Continuous | 30 HP / 20 HP |
| Spindle Nose to Table Top | 4" - 29" |
| Number of Tool Positions | 20 Station ATC |
| Rapid Traverse Rates | 1000 IPM |
| Cutting Feedrates | 650 IPM |
| Machine Dimensions | 122" x 95" x 100" |
| Machine Weight | 13,300 lbs. |
