1998 Hyundai Hit-30F
1998 Hyundai Hit-30F
$23,500 (USD)
Location:Texas
or
Call (863) 439-6066
Description
Tailstock
Chip Conveyor
12" 3 Jaw Hydraulic Chuck
RS 232 Port Interface
Complete Coolant System with Tank & Pump
All Available Tooling
All Available Manuals
Specifications
| Manufacturer | Hyundai |
| Model | Hit-30F |
| Year | 1998 |
| Condition | Used |
| Stock Number | 117706 |
| Machine Control | Fanuc O-T |
| Chuck Size | 12" 3-Jaw Hydraulic |
| Maximum Swing | 20.8" |
| Maximum Swing Over Cross Slide | 12.6" |
| Distance Between Centers | 39.37" |
| X-Axis Travel | 7.87" |
| Z-Axis Travel | 40.16" |
| Maximum Cutting Diameter | 12.6" |
| Spindle Nose / Bore / Bar Capacity | A2-8" / 3.15" / 2.75" |
| Spindle Speeds | 30-3,000 rpm |
| Spindle Motor | 30 hp |
| Number of Turret Positions | 8 Sided / 16 Positions |
| Tailstock Center | #4 MT |
| Rapid Traverse Rates X/Z | 945 ipm / 708 ipm |
| Machine Dimensions LxWxH | 136"x70:x75" |
| Machine Weight | 13,000 lbs |
