2011 Hurco TMM-8
2011 Hurco TMM-8
Contact us for price
Illinois
orCall (863) 439-6066
Description
Tailstock
Live Tooling
Rigid Tapping
Conversational Programming
Tool Eye
Serialization Engraving
All Available Manuals
Specifications
| Manufacturer | Hurco |
| Model | TMM-8 |
| Year | 2011 |
| Condition | Used |
| Stock Number | 117692 |
| Machine Control | Hurco Max |
| Chuck Size | 8" 3-Jaw Hydraulic |
| Maximum Swing Over Cross Slide | 11.8" |
| Maximum Swing over Bed | 21" |
| Distance Between Centers | 23" |
| X-axis travel | 7.8" |
| Z-Axis Travel | 20" |
| Maximum Cutting Diameter | 10" |
| Maximum Cutting Length | 17.9" |
| Spindle Nose / Bore / Bar Capacity | A2-6 / 2.4" / 2.04" |
| Spindle Motor | 18 hp |
| Spindle Speed | 4,800 rpm |
| Number of Turret Positions | 12 |
| Milling Spindle Speed | 5,000 rpm |
| Milling Spindle Motor | 6 hp |
| Machine Dimensions LxWxH | na / na / 83.7" |
| Machine Weight | 8,819 lbs |
