2011 Doosan Puma 2100Y
No longer available
2011 Doosan Puma 2100Y
$89,500 (USD)
Location:Florida
Description
Full C Axis Spindle Rotation
Live Milling / Drilling Capability
Y Axis Capability
Chip Conveyor
8" Samchully 3 Jaw Hydraulic Chuck
3 Color Machine Status Lights
Tool Presetter
Parts Catcher
Tailstock
3.5" Floppy Disk Interface
RS 232 Port Interface
All Available Manuals
All Available Tooling
Specifications
| Manufacturer | Doosan |
| Model | Puma 2100Y |
| Year | 2011 |
| Condition | Used |
| Stock Number | 117578 |
| Control | Fanuc Series 0iC |
| Chuck Size | 8" Hydraulic |
| Maximum Swing | 30.7" |
| Maximum Machining Diameter | 15.98" |
| Maximum Machining Length | 20.47" |
| Maximum Bar Capacity | 2.6" |
| X-Axis Travel | 10.2" |
| Y-Axis Travel | +/- 2.1" |
| Z-Axis Travel | 23.2" |
| Spindle Nose / Spindle Bore | A2-6" / 3" |
| Spindle Speed | 4500 RPM |
| Spindle Motor | 25 HP |
| Rotary Tool Speed / Rotary Motor | 5000 RPM / 7.5 HP |
| Number of Turret Positions | 12 Station Turret |
| Rapid Traverse Rates X, Z / Y | 1181 IPM / 393 IPM |
| Machine Dimensions | 135"x77"x85" |
| Machine Weight | 13,225 lbs. |
