1989 Okuma LC-30-2ST/250 Chucker
No longer available
1989 Okuma LC-30-2ST/250 Chucker
$15,000 (USD)
Florida
Description
Twin Turret Design
Chip Conveyor
12" 3 Jaw SMC Air Chuck (serviced with new seal kit in 2018)
Coolant Tank with Pump
RS 232 Port Interface
Heavy Duty Slant Bed with Boxed Ways
All Available Manuals
All Available Tool Blocks
*Was used most of its life in a defense contracting shop doing optics work, purchased by current owner in 2017 with anticipation of using for aluminum wheel work, but job didn't materialize, has rarely been used over the last 4 years other than on some test parts
Specifications
| Manufacturer | Okuma |
| Model | LC30-2ST/250 |
| Year | 1989 |
| Condition | Used |
| Stock Number | 117566 |
| Control | Okuma OSP-5000LG |
| Chuck Size | 12" Air Chuck |
| Maximum Swing over Bed | 19.69" |
| Maximum Turning Diameter | 17.72" |
| Maximum Turning Length | 9.06" |
| X-Axis Travel Upper Turret / Lower Turret | 11.42" / 5.9" |
| Z-Axis Travel Upper Turret / Lower Turret | 20.47" / 19.69" |
| Spindle Nose / Spindle Bore | A2-8" / 3.03" |
| Spindle Speeds | 15 - 3,000 RPM |
| Spindle Motor | 40 HP |
| Transmission | 4 Gear Ranges |
| Number of Turrets | 2 Turrets |
| Number of Turret Positions | 12 Stations + 8 Stations |
| Rapid Traverse Rates X/Z | 200 IPM / 400 IPM |
| Machine Dimensions | 152" x 93" x 81" |
