2014 Haas VF2SS with Haas Control
No longer available
2014 Haas VF2SS with Haas Control
$49,950 (USD)
Michigan
Description
4th Axis Drive & Wiring
24+1 Position Side Mounted Tool Changer
Auger Style Chip Conveyor
Programmable Coolant Nozzle
750 MB Expanded Memory
High Speed Machining
Internal High Voltage Transformer
Early Power Failure Detection Module
Rigid Tapping
USB Port Interface
RS 232C Port Interface for DNC Operation
Haas Manual
From Toolroom Environment
Roughly 6,000 Motion Hours
About 1,800 Feed Cut Hours
Wired 360-480V Electrics
*4th Axis table with trunnion is NOT included
Specifications
| Manufacturer | Haas |
| Model | VF2SS |
| Year | 2014 |
| Condition | Used |
| Stock Number | 117565 |
| Table size | 36"x14" |
| Max table load | 1,500 lbs |
| X axis travel | 30" |
| Y axis travel | 16" |
| Z axis travel | 20" |
| Spindle taper | CAT #40 |
| Spindle speed | 12,000 RPM |
| Spindle motor | 30 HP - Direct Drive |
| Spindle nose to table top | 4" - 24" |
| Number of tool positions | 24 + 1 Position Side Mount |
| Max tool weight | 12 lbs. |
| Rapid feed rate (x,y,z) | 1,400 IPM |
| Cutting feed rate | 0.1 - 833 IPM |
| Machine dimensions | 88" x 93" x 106"H |
| Machine weight (approximately) | 9000 lbs. |
